ASUS VivoBook Pro 15X OLED

Method 1: Flip the laptop over

• Close the lid and turn the laptop upside down.
• Look at the printed label near the middle or lower edge of the bottom panel.
• Find the line that reads "Model:" — it will show something like K6501ZM, M6501RM, or M6501RR.
• Some labels print the longer retail code instead, such as K6501ZM-EB74 or M6501RR-DB96. The first six characters are what matter.

Method 2: Check it on screen

• Turn the laptop on and click the Windows Start button.
• Type System Information and press Enter.
• Read the line labeled System Model — it will display your K6501 or M6501 code.
• The same window lists your Processor, which is the other answer the quote tool asks for.

Method 3: Check the box or invoice

• The retail carton prints the full SKU on the end-flap barcode label.
• Amazon, Best Buy, Newegg, and B&H order confirmations list the SKU in the product title.
• Registered your laptop with ASUS? The model appears in your MyASUS account.

Still unsure? Our ASUS model number guide walks through each step with photos.

✅ Quote it here if your label shows:

• K6501ZM or K6501ZMB — Intel Core i7 12th Gen, RTX 3060
• M6501RM — AMD Ryzen, RTX 3060
• M6501RR — AMD Ryzen 9 6900HX, RTX 3070
• Any longer code starting with those six characters, such as K6501ZM-EB74, K6501ZM-OLEDS751, or M6501RR-DB96
• Either screen type — the 2.8K OLED and the FHD 144Hz panel both belong on this page

❌ Use a different page if your label shows

• K6500, M6500, K6502, N6506, Q533 — these are the VivoBook Pro 15 (no "X"), a thinner body with RTX 3050 / 3050 Ti / 4050 / 4060 graphics
• M7601, N7601, K6604 — VivoBook Pro 16X, a 16-inch machine that uses the same 240W charger and is easy to confuse
• M7400, N7400, N7401 — VivoBook Pro 14X, the 14-inch sibling
• X1502, X1505, M1505, S5504 — mainstream VivoBook 15 and VivoBook S15, no dedicated NVIDIA graphics
• H5600, H7600, W5600 — ProArt Studiobook, a separate professional line

Processor (CPU)

• Intel — K6501: Core i7-12650H — 10 cores (6P + 4E), 16 threads, 24MB cache, up to 4.7 GHz
• Intel — K6501: Core i7-12700H — 14 cores (6P + 8E), 20 threads, 24MB cache, up to 4.7 GHz
• AMD — M6501: Ryzen 9 6900HX — 8 cores, 16 threads, 16MB cache, up to 4.9 GHz
• AMD — M6501: Ryzen 7 6800H / 6800HS — 8 cores, 16 threads
• The quote tool above lists the two volume options: Intel Core i7 12th Gen and AMD Ryzen 9 6900HX. If your unit carries a Ryzen 7 6800H or 6800HS, use our custom quote form instead.

Graphics (GPU)

• NVIDIA GeForce RTX 3060 Laptop GPU — 6GB GDDR6 (K6501ZM, M6501RM)
• NVIDIA GeForce RTX 3070 Laptop GPU — 8GB GDDR6 (M6501RR)
• Integrated graphics run alongside: Intel UHD or Iris Xe on K6501 depending on the exact i7; AMD Radeon 680M on M6501
• Important asymmetry: ASUS never shipped an RTX 3070 with the Intel platform in this chassis. The RTX 3070 exists only on AMD M6501RR units. If you believe you have an Intel + RTX 3070 combination, please double-check your label before submitting.

Memory (RAM)

• DDR5-4800, maximum 32GB total
• 16GB is soldered directly to the motherboard and cannot be removed or replaced. This is permanent and is a genuine value driver — the base memory can never be stripped out before resale, which keeps the floor price of these units stable.
• One accessible SO-DIMM slot sits alongside the soldered memory, so factory units shipped as 16GB (soldered only) or 32GB (16GB soldered + 16GB module)
• Units at 16GB run in single-channel mode because dual-channel requires a populated SO-DIMM. A 32GB unit is meaningfully faster.

Storage

• M.2 2280 NVMe solid-state drive
• Factory capacities of 512GB and 1TB, expandable to 2TB
• Intel K6501 boards carry two M.2 2280 slots — one PCIe 4.0 ×4 and one PCIe 3.0 ×4 — so a second drive may have been added after purchase
• No 2.5-inch drive bay and no optical drive

Display — two distinct panels

2.8K OLED (sold as "VivoBook Pro 15X OLED"): 15.6-inch, 2880 × 1620, 16:9, 120Hz, 0.2ms response, 400 nits SDR and 600 nits HDR peak, 100% DCI-P3, VESA Certified DisplayHDR True Black 600, PANTONE Validated, glossy finish.

FHD IPS-level (sold as "VivoBook Pro 15X"): 15.6-inch, 1920 × 1080, 16:9, 144Hz, 250 nits, 100% sRGB, PANTONE Validated, anti-glare matte finish.

Not sure which you have? The OLED has a glossy, mirror-like screen with very deep blacks. A matte screen that diffuses reflections is the FHD panel. In the US market, the Ryzen 9 6900HX + RTX 3070 configuration was sold almost exclusively with the matte FHD 144Hz panel — the "OLED" in this page title refers to the product family, not a guarantee about your specific unit. Either panel is quotable here.

Audio

Built-in stereo speaker system with ASUS Smart Amp technology and a built-in array microphone with Cortana far-field voice support. No subwoofer and no dedicated line-in jack — audio input and output share a single 3.5mm combo port.

Battery & charging

76 Whr, 4S1P 4-cell lithium-ion pack rated at 15.48V — identical across K6501ZM, M6501RM, and M6501RR. Ships with a 240W AC adapter (ASUS ADP-240EB B, 20V / 12A) using a 6.0 × 3.7 mm barrel tip. A tired battery does not disqualify your laptop; just select the matching condition option above.

Camera, mic & security

FHD 1080p webcam paired with the built-in array microphone. A fingerprint reader is integrated into the chassis for Windows Hello sign-in. This model has no infrared face-recognition camera and no smart card reader.

Keyboard & touchpad

Full-size backlit chiclet keyboard with a dedicated numeric keypad and roughly 1.4 mm of key travel. The signature VivoBook orange Esc key and the accent-colored Enter key edge are the fastest visual confirmation that you are looking at a VivoBook Pro rather than a ZenBook or ROG machine. Precision touchpad below.

Cooling

ASUS IceCool Pro thermal system with dual fans and quad vents, rated for up to 140W of combined CPU and GPU power draw. Fan noise or dust buildup doesn't block a quote—our technicians service intake paths during intake testing.

Weight

≈ 4.63 lb (2.10 kg), consistent across both platforms and both display options.

Dimensions & finishes

355.4 × 239.8 × 20.9 mm (13.99" × 9.44" × 0.82"). Offered in 0 ° Black and Earl Grey, both with diamond-cut edge chamfers along the lid and base.
